Keeping your boat’s electrical system running smoothly means paying close attention to one key factor: amperage. Whether you’re powering navigation lights, running a fridge, or just making sure your engine fires up reliably, understanding amps, amp-hours, and battery ratings is essential. The reality is that you only have a limited amount of electrical capacity on board, and managing it wisely will make the difference between smooth sailing and frustrating outages.


This guide breaks down the basics of cranking amps, deep-cycle battery ratings, and how to size your battery bank, alternator, and charger so your system can handle the demands you put on it.



Starting Batteries and Cranking Power


This deep-cycle marine/RV battery is rated for 500 MCA (marine cranking amps) and 80 amp-hours. The 140-minute reserve capacity indicates the number of minutes a battery can deliver 25 amps of current without dropping below 10.5 volts. An interesting rule of thumb is that typically if you divide a given reserve capacity by two, you will derive the approximate amp hour capacity.

Above: This deep-cycle marine/RV battery is rated for 500 MCA (marine cranking amps) and 80 amp-hours. The 140-minute reserve capacity indicates the number of minutes a battery can deliver 25 amps of current without dropping below 10.5 volts. An interesting rule of thumb is that typically if you divide a given reserve capacity by two, you will derive the approximate amp hour capacity. Image courtesy of Exide.


Not all batteries are created equal, and part of the confusion comes from how manufacturers present their ratings. The most familiar specification is the cold cranking amps (CCA) rating, which tells you how much current a battery can deliver at 0°F. In the marine world, you’ll also see marine cranking amps (MCA), which is measured at 32°F.


The difference matters: a marine battery advertised at 800 MCA won’t actually deliver 800 amps in freezing conditions. The higher number just looks more impressive on paper, which is why MCA can feel more like a marketing tool than a practical measurement.


The bottom line? Use cranking amp ratings as a rough guide, but don’t obsess over them. Boatbuilders and engine manufacturers rarely specify exact cranking requirements anymore. Instead, they give recommendations for battery group sizes and wire lengths.


If you really want to know what your starter demands, grab a clamp-on ammeter (also known as an amp clamp), place it around the starter’s positive lead, and have someone crank the engine. The reading gives you a true benchmark for your setup, as long as your battery and connections are in good condition.




A clamp-on meter set to measure amperes will help you determine the electrical demands of your system.

Above: A clamp-on meter set to measure amperes will help you determine the electrical demands of your system.


Deep-Cycle Batteries and House Loads


Once the engine is running, your focus shifts to the rest of the boat: lights, radios, pumps, refrigeration, and other DC equipment. Here, the important specification is the amp-hour (Ah) rating, which tells you how much current a battery can deliver over time.


A common way to see this expressed is the C-rate. For example:





  • A rating of 100 Ah at C-20 means the battery can theoretically supply 5 amps per hour for 20 hours before dropping below 10.5 volts.




  • At higher discharge rates, the usable capacity goes down. This is described by Peukert’s Law, which explains why batteries don’t perform in a perfectly linear way.




To make things more practical, most boaters work with the C-20 rating. Historically, you’d only plan to use about 50% of a battery’s capacity to extend its cycle life. These days, some modern deep-cycle batteries can handle up to 80% discharge without damage, though that often comes with a higher price tag.


When comparing batteries, look at its:





  • C-20 rating for realistic capacity




  • Allowable depth of discharge (50% vs. 80%)




  • Cycle life (how many charge/discharge cycles you’ll get)




  • Cost per amp-hour as a way to compare value




Figuring Out Your Amp-Hour Needs


Before you can size a battery bank or charging system, you need to understand how much power your boat actually uses. To do this, start with a load analysis.





  1. Use a clamp meter to measure the current draw of each circuit.




  2. Separate equipment into different categories:





    • Mission-critical equipment: navigation lights, radios, GPS, bilge pumps, and more




    • Intermittent loads: cabin lights, windlass, accessory sockets, etc.




    • Constant but non-critical loads: refrigerators, certain pumps, etc.






  3. Add up 100% of the mission-critical loads.




  4. Add either the single highest-draw item from the other categories, or about 10% of their total load.




To make an accurate assessment of your boat's requirements for both mission-critical and less important demands, use a load requirements worksheet like this example from the American Boat and Yacht Council.

This gives you a working number for your DC demand. With that figure, you can decide what size battery bank, alternator, and charger your boat really needs.



Alternators and Battery Chargers


Once you know your load requirements, you can use this info to accurately size your charging system. The goal is simple: your alternator should be able to power all critical loads while also recharging your batteries.





  • Alternators: Choose one with some margin. An alternator that constantly runs at full output will wear out quickly, so aim for 75% of its rated capacity during regular use.




  • Battery chargers: Traditionally, a charger only needed to supply 25% to 30% of a battery’s amp-hour rating. For a 100 Ah battery, that means a 25 to 30 amp charger will be sufficient. But with newer batteries boasting higher acceptance rates (up to 60%), higher-output chargers are both practical and efficient.




Bear in mind that installing a new high-output alternator on an older engine will probably require other modifications, too.

Above: Bear in mind that installing a new high-output alternator on an older engine will probably require other modifications, too.



Upgrading to modern high-tech batteries often means you’ll need to review other parts of your system as well, including your voltage regulator, over-current protection, and even wiring.

Modern battery technology can mean a higher acceptance rate for charging, which in turn means that buying a higher-output charger  might be a smart decision. However, bear in mind the other elements in the system that might also need upgrades. Photo courtesy of ProSport.

Above: Modern battery technology can mean a higher acceptance rate for charging, which in turn means that buying a higher-output charger might be a smart decision. However, bear in mind the other elements in the system that might also need upgrades. Photo courtesy of ProSport.


Boat Amperage and Battery Capacity: Putting It All Together


Understanding how amps and amp-hours relate to your boat’s electrical system isn’t just about numbers. It’s about knowing your limits, planning for your needs, and protecting your equipment (and your money!). By taking the time to measure loads, compare battery ratings carefully, and size your alternators and chargers appropriately, you’ll keep everything from safety gear to creature comforts running reliably on the water.


The real takeaway here? Don’t just buy the biggest battery or charger you see. Match your system to your actual needs, and you’ll save money, avoid headaches, and get longer life out of your equipment.


Note: This article was originally published in February 2016 and last updated in September 2025.
